What factors determine whether copper or aluminum is used as a cable conductor material?

When choosing cable conductor materials, the use of copper and aluminum is mainly affected by the following factors:

1. Conductivity
   Copper's conductivity: Copper's conductivity is about 100% IACS (International Annealed Copper Standard), which is much higher than aluminum's conductivity (about 61% IACS). This makes copper more suitable for scenarios that require high conductivity.
   Aluminum's conductivity: Despite its lower conductivity, aluminum's lightweight and lower cost make it competitive in many scenarios.
   2. Mechanical properties
   Copper's mechanical strength: Copper has high tensile strength, good fatigue resistance, and is not easily broken by bending or vibration. It is suitable for scenarios that require high mechanical strength (such as elevator cables and mining cables).
   Aluminum's mechanical strength: Aluminum is softer and has poor fatigue resistance, and may require a larger cross-sectional area to compensate for its lack of mechanical properties.
   3. Weight
   Copper's weight: Copper is about 70% heavier than aluminum, so it may not be economical when used for long distances or scenarios that require lightweight.
   Aluminum weight: Aluminum's lightweight properties make it more advantageous in scenarios that require weight reduction, such as aerospace and power transmission lines.
   4. Cost
   Copper cost: Copper is usually about three times more expensive than aluminum, so copper cables have a higher initial cost.
   Aluminum cost: Aluminum has a lower cost, making it more attractive for projects with limited budgets.
   5. Corrosion resistance
   Copper corrosion resistance: Copper has good corrosion resistance in most environments, but may be affected in sulfur-containing environments.
   Aluminum corrosion resistance: A layer of aluminum oxide protective film forms on the surface of aluminum, but special treatment (such as coating) may be required in high humidity or acidic environments.
   6. Application scenarios
   Copper application: Suitable for scenarios that require high reliability and performance, such as high-voltage cables, building wiring, and industrial equipment.
   Aluminum application: Mostly used in scenarios that require lightweight and low cost, such as high-voltage transmission lines and outdoor overhead cables.
   7. Connection and installation
   Copper connection performance: Copper wiring has higher reliability, and the joints are not easy to loosen or overheat.
   Aluminum connection performance: Aluminum conductors require special terminals or treatments (such as preventing creep and oxidation) when wiring.

Common cable types (such as low-voltage cables, high-voltage cables, fiber-optic cables, etc.) are suitable for which specific scenarios?

1. Low Voltage Cable

Features: The working voltage is usually no more than 1kV, the conductor material is mostly copper or aluminum, and the insulation material is commonly PVC or XLPE.

Application scenarios:
Building power distribution: used for power distribution in residential and commercial buildings, such as lighting, sockets and other low-voltage equipment.

Industrial use: connection of low-voltage equipment within the factory.

Control cable: low-voltage control system and signal transmission.

2. Medium Voltage Cable

Features: The working voltage range is usually 1kV to 35kV, and it is often used in local distribution networks.

Application scenarios:
Urban power distribution: used to distribute electric energy from substations to secondary distribution networks in cities or industrial areas.

Industrial field: such as power supply for medium-voltage equipment such as mines and ports.

Wind power generation: connect wind turbines and power grids.

3. High Voltage Cable

Features: The operating voltage range is usually 35kV to 220kV and above, with high design requirements, and the insulation materials are mostly XLPE or oil-paper insulation.

Application scenarios:
Long-distance power transmission: used for high-voltage transmission lines to transmit electricity from power plants to cities.

Substation connection: connect power plants, substations and distribution networks.

Heavy industrial equipment: provide power for high-voltage equipment.

4. Ultra High Voltage Cable

Features: The operating voltage exceeds 220kV, the technology is complex, and gas insulation or special insulation materials are usually used.

Application scenarios:
Long-distance power transmission system: cross-regional and cross-national transmission lines.

Key energy projects: such as the transmission trunk lines of nuclear power plants and large hydropower stations.

5. Optical Fiber Cable

Features: It uses optical signals to transmit data, with advantages such as high bandwidth, low loss, and anti-electromagnetic interference.

Application scenarios:
Telecommunication networks: backbone networks, metropolitan area networks and access networks.

Internet communication: data center interconnection, home broadband access.
Industry and monitoring: industrial automation network, security monitoring system.
Special environment: high electromagnetic area that needs to resist interference.

6. Shielded Cable

Features: with metal shielding layer, excellent anti-electromagnetic interference performance.
Application scenario:
Industrial control: prevent signal interference, used in control systems such as PLC, DCS.
Medical equipment: high-precision signal transmission.
Audio and video transmission: prevent signal noise.

7. Fire-Resistant Cable and Flame-Retardant Cable

Features: Fire-resistant cable can continue to supply power in a fire, and flame-retardant cable can slow down the spread of fire.
Application scenario:
Safe places: high-rise buildings, subways, airports, tunnels, etc.
Emergency system: fire pumps, emergency lighting and communication systems.

8. Special cable

Features: designed according to special environments or needs, materials and structures have specific functions.
Common types and applications:
Mining cables: suitable for harsh environments in mines, wear-resistant and high-voltage resistant.
Submarine cables: used for submarine power or data transmission.
High-temperature resistant cables: used in high-temperature environments such as aerospace and steel mills.
